EPS Grey Insulation Expanded Polystyrene 1200x600mm
EPS Grey Insulation Expanded Polystyrene 1200x600mm
Regular price
£53.86
Regular price
Sale price
£53.86
Unit price
/
per
Couldn't load pickup availability
The following thicknesses: 100mm ,120mm, 130mm, 140mm, 150mm, 170mm, 180mm, 200mm, 250mm lead time is 3-5 working days
| Thickness | Sheets per pack | Pack coverage |
| 20mm | 30 sheets | 21.6m² |
| 30mm | 20 sheets | 14.4m² |
| 40mm | 15 sheets | 10.8m² |
| 50mm | 12 sheets | 8.64m² |
| 60mm | 10 sheets | 7.2m² |
| 70mm | 8 sheets | 5.76m² |
| 80mm | 7 sheets | 5.04m² |
| 90mm | 6 sheets | 4.32m² |
| 100mm | 6 sheets | 4.32m² |
| 120mm | 5 sheets | 3.6m² |
| 130mm | 4 sheets | 2.88m² |
| 140mm | 4 sheets | 2.88m² |
| 150mm | 4 sheets | 2.88m² |
| 170mm | 3 sheets | 2.16m² |
| 180mm | 3 sheets | 2.16m² |
| 200mm | 3 sheets | 2.16m² |
| 250mm | 2 sheets | 1.44m² |
Technical Information
|
Thickness: 20mm - 150mm
Width: 600mm
Length: 1200mm
Thermal Conductivity: 0.038W/mK
R-Value: 1.97W/(m2K)
Weight/m²: 1.13kg
Pack coverage: 0.72m²
Compressive Strength: 70kPa
Water vapour resistivity: 20-40 MN.s/g.m
Fire Rating (Reaction to Fire): E |
EPS Grey Insulation Expanded Polystyrene 0.72m²
Graphite EPS is a lightweight cellular plastic material suitable for a wide range of building-insulation applications. It is an excellent insulating medium which exhibits consistent thermal performance over the range of temperatures normally encountered in buildings.
The material is versatile, light in weight, clean and easy to handle, and provides a cost-effective means of including permanent insulation in floors, walls and roofs to meet, and exceed, the standards laid down in the building regulations.
